Solar Panel Carport 5L-6 Double-Row
Designed for high-throughput parking sites, this double-row solar carport combines dependable on-site generation with full-coverage weather protection in a compact footprint. A back-to-back layout minimizes posts in traffic lanes, preserves clear drive-aisle heights, and scales efficiently across large lots. The hot-dip galvanized steel frame offers long-term corrosion resistance and structural rigidity, while the landscape module orientation keeps the profile low and cable runs tidy for fast installation and straightforward O&M. Ideal for workplaces, retail parks, fleet depots, and transit hubs, the system helps cut operating costs, improve sustainability metrics, and elevate the user experience with shaded, comfortable bays.
Capacity: 30 panels (landscape orientation); panel dimensions 2278 × 1134 × 30 mm
Kit includes:
- Galvanized steel poles (support posts)
- Main beams
- Transverse purlins
- Bracing members for structural reinforcement
- Complete set of high-strength galvanized bolts (class 8.8)
- Aluminum clamps for panel fixation
Solar panels
Foundation system
Info: The photovoltaic panels have standard dimensions of 2278 × 1134 × 30 mm, with the tilt angles listed above. For other sizes or angles, please specify in your quote request.
Solar Panel Carport 5L-6 Double-Row
The Solar Panel Carport 5L-6 Double-Row is a premium photovoltaic canopy solution designed by Pro Solar Tech for large-scale parking facilities that require both robust energy generation and reliable vehicle protection. With its back-to-back layout, the system covers two rows of vehicles under one continuous canopy, minimising the number of support posts in traffic areas and preserving clear drive aisles for smooth circulation. This design not only optimises space usage but also ensures convenient user access while supporting significant energy yield.
Built from hot-dip galvanised steel, the structure provides long-term corrosion resistance and structural rigidity, ensuring durability under heavy wind and snow loads. By using a landscape orientation, the carport maintains a lower profile, enhancing aesthetics while simplifying cable routing for neat layouts and efficient servicing. Each canopy supports thirty panels, producing dependable renewable energy while delivering shaded, weather-protected parking spaces.
The 5L-6 Double-Row system is particularly well suited to workplaces, retail parks, transit hubs, and fleet depots where high throughput and scalability are essential. Its modular configuration allows rapid installation, predictable project timelines, and straightforward maintenance. For operators and investors, it represents a reliable, cost-effective way to reduce operating expenses, improve sustainability performance, and add tangible value to parking facilities.
Advantages of Solar Panel Carport 5L-6 Double-Row
- Dual-purpose infrastructure with maximised land use: The 5L-6 Double-Row transforms parking areas into productive assets by combining weather-protected bays with renewable energy generation. This dual functionality allows site owners to achieve sustainability goals without dedicating additional land for solar farms. For businesses and municipalities, it means turning everyday infrastructure into a cost-saving and revenue-generating investment while improving the customer and employee experience.
- Durability and long-term reliability: Manufactured from hot-dip galvanised steel and assembled with class 8.8 high-strength bolts, the 5L-6 system is engineered for decades of reliable service. Reinforced with purlins and bracing members, it withstands heavy wind loads, snow accumulation, and environmental stress. The use of corrosion-resistant materials ensures minimal degradation over time, lowering maintenance needs and protecting the long-term return on investment. For investors, this durability guarantees stable performance and predictable output.
- Efficient back-to-back design: The double-row layout minimises the number of structural posts by sharing support elements between two rows of bays. This reduces material usage, cuts construction costs, and keeps drive lanes clear for vehicle manoeuvring. The design preserves generous clearance heights, ensuring compatibility with diverse vehicle types, including commercial vans and buses. For EPC contractors and operators, this design efficiency improves project economics and simplifies deployment on large parking sites.
- Simplified installation and operation: The modular structure of the 5L-6 Double-Row accelerates installation with prefabricated components, pre-drilled holes, and standardised fasteners. This reduces labour costs and compresses project timelines. Once operational, integrated cable management ensures tidy runs and easy accessibility for inspection and servicing. Panel replacements and routine cleaning can be carried out without dismantling large sections of the canopy, keeping downtime minimal and operations efficient.
Compatible photovoltaic panels
The Solar Panel Carport 5L-6 Double-Row is optimised for photovoltaic modules with dimensions of 2278 × 1134 × 30 mm, a standard format widely used by Tier 1 manufacturers. This ensures secure fixation, compatibility with high-efficiency technologies, and long-term procurement flexibility. We can also manufacture customised structures for other dimensions and types of photovoltaic modules.
Capacity
30 panels/structure
Each 5L-6 Double-Row carport supports thirty photovoltaic modules arranged in landscape orientation. With module dimensions of 2278 × 1134 × 30 mm, this layout balances strong energy yield with a compact canopy design that ensures full bay coverage and reliable protection for parked vehicles.
Foundation system
Reinforced concrete footings – designed for stability, durability, and vibration resistance in parking environments. Footings are cast in place with embedded anchor bolt cages and engineered per site-specific geotechnical conditions, wind and snow loads, and frost depth.
System components
- Galvanised steel poles (support posts)
- Main beams
- Transverse purlins
- Bracing members for structural reinforcement
- Complete set of high-strength galvanised bolts (class 8.8)
- Aluminium clamps for panel fixation
| Solar panels | |
|---|---|
| Foundation system |
